Goudsmit magnets

Your ultimate partner in waste recycling industry

info@eco-trade.ae

Advised max. installation height	300 mm
Weight	465 kg
Conveying length	2910 mm
Conveyor (belt) speed	1,5 m/s
Belt width	550 mm
Magnet dimensions	830 x 470 x 85 mm
Motor power supply	230/400 V AC; 50 Hz; 1.5 kW
length	1450 mm
Width	960 mm
Height	635 mm

Advised max. installation height	300 mm
Weight	520 kg
Conveying length	3210 mm
Conveyor (belt) speed	1,5 m/s
Belt width	550 mm
Magnet dimensions	980x470x85 mm
Motor power supply	230/400 V AC; 50 Hz; 1.5 kW
length	1600 mm
Width	960 mm
Height	635 mm

Advised max. installation height	300 mm
Weight	605 kg
Conveying length	3610 mm
Conveyor (belt) speed	1,5 m/s
Belt width	550 mm
Magnet dimensions	1180x470x85 mm
Motor power supply	230/400 V AC; 50 Hz; 1.5 kW
length	1800 mm
Width	960 mm
Height	635 mm

Advised max. installation height	300 mm
Weight	690 kg
Conveying length	4000 mm
Conveyor (belt) speed	1,5 m/s
Belt width	550 mm
Magnet dimensions	1380x470x85 mm
Motor power supply	230/400 V AC; 50 Hz; 1.5 kW
length	2000 mm
Width	960 mm
Height	635 mm

Not sure what you need? Contact us!
